LB-K
The LB-K series is an extension of Oleo’s longstanding, market leading LB series.
Expanded Capability, Proven Pedigree: The LB-K Series
The LB-K Series represents the high-capacity evolution of our legendary LB range. Engineered for medium-to-high speed travel, the LB-K utilises advanced gas-spring technology to deliver a robust safety solution for elevators with increased mass requirements. It takes the world-class performance of the LB series and extends its reach, providing the same premium protection for the heavier, more complex elevator systems of the modern age.
Why the LB-K Series is the Ultimate High-Mass Solution:
-
Extended Mass Performance: Designed as a specialised extension of our core gas-spring range, the LB-K is precision-tuned to handle higher mass loads with the same controlled, sophisticated deceleration our customers expect.
-
A Legacy of Trust: The LB-K is built on a foundation of excellence. Its parent range, the LB series, has been the “Gold Standard” in thousands of landmark buildings worldwide for over 30 years – ensuring the LB-K arrives with a proven engineering pedigree.
-
Logistical Efficiency: Just like our standard LB units, the LB-K can be shipped in a compressed state. This space-saving innovation reduces your storage requirements and lowers transportation costs, keeping even the largest projects lean and efficient.
-
Globally Certified Excellence: Manufactured under Oleo’s uncompromising engineering principles, the LB-K series is fully market-certified and designed to meet the world’s most stringent international safety codes.
The LB-K Series: Extending the legacy of the world’s most trusted medium-high-speed buffer to a broader range of mass possibilities.
- Energy dissipation buffer
- Minimum G-force experience (increased passenger protection)
- Lowest possible compressed height for specified mass range
- Certified to KC
- Wide mass range 850-7000 kg
- Self contained, maintenance free (except statutory inspections) unit
- Gas spring return
- All supporting documentation available online
Model & Parameter
| Buffer Type | LB 25.KL | LB 32.K | LB 35.K | LB 40.K | |
| Rated Speed | m/s | 2.54 | 3.15 | 3.56 | 4.06 |
| Stroke (min) | mm | 461.9 | 698.9 | 880.9 | 1140.9 |
| Mass range (Min) | Kg | 850 | 1500 | 1500 | 1500 |
| Mass range (Max) | Kg | 7000 | 7000 | 7000 | 7000 |
| Height (Extended) Dim H (Max) | mm | 1210.9 | 1705.9 | 2107.9 | 2692.9 |
| Height (Compressed)Dim C (Min） | mm | 731.3 | 989.3 | 1209.3 | 1534.3 |
| Approx Weight (without oil) | Kg | 38.59 | 55.22 | 66.44 | 81.85 |
| Oil Volume | Litres | 10 | 20 | 24.2 | 31.5 |
