MLB-K
Our MLB-K series is an extension of Oleo’s MLB series. MLB-K buffers are smaller and weigh considerably less than many direct alternatives for speed and mass.
Precision Tuning for Specialised Mid-Range Mobility:
The MLB-K Series
The MLB-K Series is the specialised evolution of the MLB range, specifically tuned to provide a premium safety interface for elevators with a mass range of 1,000 kg to 5,000 kg. Utilising the same elite gas-spring technology found in our high-speed ranges, the MLB-K offers a robust and highly targeted solution for mid-mass systems. It is the ideal choice for developers seeking the reliability of the MLB series with a refined mass-calibration for specific project requirements.
Why the MLB-K Series Delivers Targeted Excellence:
-
Refined Mass Range: Precision-engineered to bridge specific performance gaps, the MLB-K offers a dedicated solution for elevator systems between 1,000 kg and 5,000 kg, ensuring optimal deceleration and passenger comfort.
-
Space-Efficient Gas-Spring Design: Enjoy the superior performance of a gas-spring system in a compact envelope. The MLB-K is significantly smaller and lighter than many alternatives, maximising usable space within the hoistway.
-
Ready-to-Install Convenience: Our MLB-K 20-32 units can be supplied pre-filled with oil, accelerating your installation timeline, reducing logistical complexity, and ensuring the unit is factory-perfect upon arrival.
-
Rigorous Market Certification: Built to Oleo’s uncompromising engineering principles, the MLB-K is fully market-certified, providing an established and trusted safety solution that meets the world’s most stringent codes.
The MLB-K Series: Targeted engineering and gas-spring sophistication for the modern mid-range elevator.
- Energy dissipation buffer
- Minimum G-force experience (increased passenger protection)
- Lowest possible compressed height for specified mass range
- Smallest space envelope possible
- Reduced weight means that shipping costs are significantly lower
- Certified to KC
- Wide mass range 1000-5000 kg
- Self contained, maintenance free (except statutory inspections) unit
- Gas spring return
- All supporting documentation available online
Application
Model & Parameter
| Buffer Type | MLB 20.1 | MLB 25.1 | MLB 32.1 | MLB 35.3 | MLB 40.3 | |
| Rated Speed | m/s | 2.03 | 2.54 | 3.15 | 3.56 | 4.06 |
| Stroke (min) | mm | 280.3 | 436.3 | 680.3 | 880.9 | 1140.9 |
| Mass range (Min) | Kg | 1000 | 1000 | 1000 | 1000 | 1000 |
| Mass range (Max) | 5000 | 5000 | 5000 | 5000 | 5000 | |
| Height (Extended)Dim H (Max) | mm | 782.3 | 1164.3 | 1730.5 | 2107.9 | 2692.9 |
| Height (Compressed) Dim C(Min） | mm | 488.4 | 714.4 | 1034 | 1209.3 | 1534.3 |
| Approx Weight (without oil) | Kg | 15.02 | 21.05 | 29.72 | 61.45 | 75.66 |
| Oil Volume | 2.18 | 3.32 | 5.19 | 19.5 | 25 |
